Force
Our strongest, toughest, and most versatile flail mower yet, the Trimax Force is highly customizable to perfectly suit your application.
A HIGH-UTILITY HEAVY-DUTY POWERHOUSE.
The Trimax Force is the multitool mower and mulcher you need to get the job done, no matter what that job might be. Turn long grass and large prunings into an expertly trimmed and finely mulched field in a single pass. Our strongest and most adaptable flail mower yet, with a wide range of options available for configuring and customising your machine, the Trimax Force can be tailored to perfectly suit all your mowing and mulching needs.
Building on the successes of the Trimax Warlord, we’ve introduced new features to expand on the qualities for which Trimax mowers are already renowned, reducing maintenance requirements and increasing safety to unprecedented levels all while retaining an ultra-low cost of ownership. Together with local parts and service teams standing by to support you, we’re making it easier than ever to accomplish your mowing and mulching goals. No hassles, no worries, just reliable products, and excellent results.
Designed and manufactured in New Zealand and backed by 40 years of experience producing premium flail mowers, the Trimax Force is a force to be reckoned with.
Talk to us today about the capabilities of Force in your environment.
Force Features.
The below features come as standard on all Force mowers:
MOW AND MULCH WITH ONE MACHINE
Mow grass to a fine finish and mulch prunings up to 3.5″ in diameter with one machine.
REPLACEABLE INTERNAL LINER
A 1/4″ replaceable internal liner reduces noise and increases mower life.
LOW MAINTENANCE
Easily accessible grease locations and maintenance-free features for simple servicing.
MAINTENANCE-FREE ROLLER BEARINGS
New highly-rated sealed roller bearings require no regular greasing.
DISCHARGE CONTROL
The coarseness of mulch is controlled by the height of the rear flap, fully open for easy service access.
SMOOTH PROFILE
New internal rotor bearings create a smooth external profile and provide a closer cut around obstacles.
AUTOMATIC BELT TENSIONERS
Eliminates the need for belt adjustments and improves drive to the rotor.
REPLACEABLE SKIDS
Wear skids on trailing arms prolong mower life in demanding terrain.
ROBUST ROLLER
Replaceable robust roller with 3/16″-thick walls for tough applications.
PRUNING GUIDE
Helps direct prunings and other foliage into the front aperture of the mower.
SAFETY COMPLIANT
Meets international safety standards in every configuration.
3 YEAR WARRANTY
We build mowers that last and they’re supported with a 3-year industry-leading warranty.
Force Options.
Heavy Duty Roller
Upgrade from the 5mm thick roller to a roller with 11mm wall thickness. Suitable for more demanding applications.
Front Mount
Available in front mount three-point linkage configuration for increased visibility. Suitable for tractors with front PTO drive only. Available on all base configurations.
HYDRAULIC SIDE SHIFT
Position directly behind the tractor or quickly offset by up to 500mm (19″) for easy transport and increased maneuverability. (Available only for 175, 205, and 235.)
STORAGE BOX
The Storage Box can be mounted to the mower with the Lighting Kit with Storage Bracket for easy access to spare parts and tools in the field.
Roller Scrapers
Trimax Helical Scrapers operate with reduced tension but apply a constant pressure across the roller to assist with the cleaning of debris.
HEAVY DUTY LINER
Increase the life of your replaceable internal liner by three times with a heavy-duty internal liner, suitable for high-wear applications.
MULCHING COUNTERBLADES
An internal liner with built-in blades for extra material processing. Can produce ultra-fine mulch.
PRUNING RAKES
Collects prunings and branches into the mower-cutting chamber for more efficient mulching. Ideal for stony ground conditions.
LEFT-HAND OR RIGHT-HAND OFFSET
Force can be configured with a left-hand or right-hand offset for increased over-the-shoulder visibility in special applications. Left-hand offset is recommended for roadside use. (Available only for 175, 205, and 235.)
Lighting Kit with Storage Bracket
The Lighting Kit with Storage Bracket mounts LED road lights and a safety triangle to the mower for commercial use. It also mounts a bracket for holding a storage box (sold separately).
SAFETY DISPERSION GUARD
Recommended for all mowers operating in public spaces, the Safety Dispersion Guard ensures that debris exits the cutting chamber safely.
SERVICE KIT
Full set of blades, bolts and belts for a quick routine service.
Force OFFSETS.
Left-hand or right-hand offsets and hydraulic side shift are only available for Force 175, 205, and 235.
SPECIFICATIONS.
|
Cutting Width |
1.15m (3′ 9 1/4″) |
Approx. Weight |
590 kg (1300 lb) |
|
Overall Width |
1.45m (4′ 8 7/8″) |
Minimum PTO Output * |
30 hp |
|
Overall Length |
1.15m (3′ 9 1/4″) |
No. of Flails |
16 |
|
Overall Height |
0.5m (1′ 7 3/4″) |
Hydraulic Side Shift |
No |
|
Cut Height Range |
0- 60mm (0- 2 3/8″) |
Workrate (6 mph) |
0.69 hectares/hr |
|
Cutting Width |
1.44m (4′ 8 3/4″) |
Approx. Weight |
650kg (1435lbs) |
|
Overall Width |
1.73m (5′ 8 1/4″) |
Minimum PTO Output * |
35 hp |
|
Overall Length |
1.15m (3′ 9 1/4″) |
No. of Flails |
20 |
|
Overall Height |
0.5m (1′ 7 3/4″) |
Hydraulic Side Shift |
No |
|
Cut Height Range |
0 – 60mm (0″ – 2 3/8″) |
Workrate (6 mph) |
0.87 hectares/hr |
|
Cutting Width |
1.73m (5′ 8 1/8″) |
Approx. Weight |
755kg (1665lbs) |
|
Overall Width |
2.02m (6′ 7 5/8″) |
Minimum PTO Output * |
40 hp |
|
Overall Length |
1.15m (3′ 9 1/4″) |
No. of Flails |
24 |
|
Overall Height |
0.5m (1′ 7 3/4″) |
Hydraulic Side Shift |
No |
|
Cut Height Range |
0 – 60mm (0″ – 2 3/8″) |
Workrate (6 mph) |
1.04 hectares/hr |
|
Cutting Width |
2.02m (6′ 7 3/8″) |
Approx. Weight |
815kg (1795lbs) |
|
Overall Width |
2.31m (7′ 7″) |
Minimum PTO Output * |
45 hp |
|
Overall Length |
1.15m (3′ 9 1/4″) |
No. of Flails |
28 |
|
Overall Height |
0.5m (1′ 7 3/4″) |
Hydraulic Side Shift |
No |
|
Cut Height Range |
0 – 60mm (0″ – 2 3/8″) |
Workrate (6 mph) |
1.26 hectares/hr |
|
Cutting Width |
2.3m (7′ 6 3/8″) |
Approx. Weight |
870kg (1920lbs) |
|
Overall Width |
2.59 (8′ 5 7/8″) |
Minimum PTO Output * |
50 hp |
|
Overall Length |
1.15m (3′ 9 1/4″) |
No. of Flails |
32 |
|
Overall Height |
0.5m (1′ 7 3/4″) |
Hydraulic Side Shift |
No |
|
Cut Height Range |
0- 60mm (0- 2 3/8″) |
Workrate (6 mph) |
1.38 hectares/hr |
